ITX in Barebone Sistemi
Spletna cena z DDV
Zaloga:
Šifra izdelka: CV863A-4R10E
Značilnosti:
VIA Eden C3 , 4LAN , 2 PCMCIA
Specifications:
. CPU type:
On-board VIA C3/ Eden 376 PIN EBGA package
. Front Side Bus:
100/133 MHz
. MB Vezni nabor:
VIA PLE266 VT8623A+ VT8235
. Graphics:
Integrated with VT8623
Shared system memory up to 64MB
. Memory:
1 x DDR SDRAM (max. 512MB)
. IDE:
Ultra DMA-133/100/66 transfer protocols
1 x 40 pin 2.54mm, 1 x44 pin 2.0mm
Support Compact Flash card type II for ATA interface
. Sound:
AC’97 2.2, support 2 channel audio
. LAN:
4 x Realtek 10/100 Mbps
. USB:
5 x USB 1.1/2.0
. I/O:
One 16C550 UARTs RS232 port support
. PCMCIA:
Richo R5C486 PCMCIA chipset compliant PCI with ver.2.2
Supports 2x sockets, for Cardbus(Card 32) and 16-bit Card
. Expansion interface:
1 x PCI gold finger, rev. 2.2 interface
. Power:
On board power DC +12V±5% convert into system
+3.3V/+12V/+5V
. Dimension:
200 x 150 mm
. Operation Temperature:
0 ~ 45°C
. Operation Humidity:
5~95% @ 45°C, non-condensing
Ordering Information:
. CV863A-4R10E : 4 LAN, PCMCIA, Eden 1GHz
